PRODUCT

AF 85mm F1.4 FE

Delivering sharpness

with beautiful bokeh

AF 85mm F1.4 FE

The AF 85mm F1.4 FE is inspired by the optical vision of the MF 85mm F1.4 AS IF UMC, which has been loved for its beautiful out-of-focus images since its launch in 2008: however, this new lens develops the original’s existing strengths with a much more advanced optical design, newly optimized for mirrorless cameras. This lens of great value and charm with high resolution encapsulates Samyang’s universally respected 40-year optical technology in your photographs.

작성자 Product Planner Jihoon Lee
제품 이미지
제품 이미지
제품 이미지
제품 이미지
제품 이미지
제품 이미지
제품 이미지
제품 이미지
제품 이미지
제품 이미지

Optical performance, and photographs with emotional punch

Delivering sharpness with beautiful bokeh

The AF 85mm F1.4 FE cherishes Samyang’s world class optical technology while envisioning a new leap forward, with its quick and accurate autofocus performance and excellent resolution.
Its complex optical construction is comprised of 11 glass elements, among which are special High Refractive (HR) glass, which successfully allow both a compact size and high image resolution. The achromatic design, incorporating Extra Low Dispersion (ED) glass, effectively corrects chromatic aberrations and minimizes peripheral softness, creating lively images in vivid colors.






  • Exceptional rendering even at the brightest apertures

    The AF 85mm F1.4 FE’s optical design minimizes optical aberrations, while maximizing the image quality from corner to corner. Its detailed rendering results in exceptional image quality, even on the latest high-resolution full-frame cameras; and its bright maximum aperture means you can enjoy this excellent performance even when shooting indoors or in darker conditions.


  • Exceptional bokeh

    The lens’s attractive bokeh, created through precise lens polishing, adds a great feeling of depth and space in your photographs. Also, its aperture mechanism comprises 9 precisely-controlled iris blades, providing natural, circular, out-of-focus highlights at all apertures. With this smooth bokeh, achieved through various optical technologies, you can create images full of character in your portrait or subject photography.


  • Expressing a visual feeling of depth

    The short telephoto focal length, combined with the wide maximum aperture of f/1.4, enables photographers to achieve a dramatically shallow depth-of-field, setting your pictures apart from those taken with other lenses. This optic offers great creative freedom: it yields images with depth, while maintaining an appropriate distance from the subject; it separates subject and background naturally, providing an impressive visual feeling of depth.


  • Controlling chromatic aberration with ED glass

    The AF 85mm F1.4 FE features a total of 11 glass elements; the ED (Extra Low Dispersion) elements have been incorporated into its precise achromatic design. This design corrects chromatic aberrations, and creates quality results, with peripheral softness also being well-controlled.




  • Designing a complex optical system with High Refractive elements

    Four HR (High Refractive) elements, made of special materials with an outstanding refractive index, improve optical performance and enable a compact optical design. The AF 85mm F1.4 FE was designed from the ground-up with this technology, to lessen its users’ burden with a shorter length and smaller size.


  • Fast and efficient autofocus with DLSM Technology

    DLSM (Dual Linear Sonic Motor) works with ultrasonic vibrations, which cannot be heard by human ears, to successfully give a silent autofocus performance. The accurate high frequency signals, controlled with Samyang’s own protocols, precisely operate the DLSM. Specialists in optics, mechanical engineering, and electronics, have researched cooperatively to give these powerful results for a short telephoto lens. The introduction of DLSM technology on an 85mm lens means you can comfortably and silently capture the subjects you want, with quick efficiency.


  • Weather sealing design for protection from adverse conditions

    The aluminum body, designed with precision by mechanical engineering specialists, has only three spaces in its basic design. Weather sealing covers even these small spaces to effectively protect the lens from dust and rain. This protective design enables users to capture the moment outdoors in any environment, providing the dependability you need to keep shooting.


  • Outstanding contrast with Ultra Multi Coating (UMC) technology

    Samyang’s Ultra Multi Coating (UMC) technology is applied through a thorough cleaning process, followed by Ion-Beam Sputtering (IBS), which controls the spread of reflections while still enabling a high transmittance of light. This UMC technology reduces unwanted reflections and provides crystal clear image quality, minimizing flare and ghosting effects in high contrast environments, such as backlit pictures and nightscapes.


  • Its compact and lightweight design elevates it to the best in its class for an 85mm F1.4 lens

    The AF 85mm F1.4 FE is a medium-telephoto lens with a very bright aperture. Thanks to its compact optical design and aluminum construction, it can be contained within a small and lightweight body, enabling photographers to carry and handle a lens of this type with ease.

Technical Information
  • Specifications
    Model name AF 85mm F1.4 FE
    Aperture range F1.4 ~ F16
    Lens optical construction 11 Elements in 8 Groups
    Special lens HR 4, ED 1
    Coating UMC
    Minium focusing distance 0.90m (2.95ft)
    Magnification Ratio x 0.11
    Diaphragm Blades 9
    Filter size 77.0mm
    Maximum Diameter 88.0mm
    Mount Sony FE
    Angle of view Full Frame 28.9˚
    APS-C 19.1˚
    Length 99.5mm
    Weight 568g
    Weather Sealing o
    AF/MF mode switch X
    AF MotorDLSM
  • MTF Chart







  • Optical construction





We noticed that you are accessing from United-States of America.

If you're looking for another location, please select your location.

Country/ Region
Online shop
GO
Newsletter Feedback Shop
Now

Samyang’s Guide to Achieving the Optimal Angle of View

The perfect spacing and distance are always necessary when shooting all kinds of subjects, including people, to give them a proper relationship with the beautiful space around them. So, what’s the exact distance that helps you best appreciate a work of art, or a photo?

The correct answer is the diagonal length of the full frame of a subject.

표준화각 자료 이미지
표준화각 자료 이미지

The best standpoint from which to appreciate the full view of a subject is the distance of the diagonal length of the subject frame. This wider angle is superior to standing closer at a 50 degree angle to get a more detailed view. This notion of an ideal distance or view point is also applicable in the world of photography.

For still images, keeping a distance equal to the diagonal length of the full image surface is recommended. The full frame sensor of a digital camera is 36 x 24mm and the diagonal length is 43.26mm so any distance close to this number is nearer to the ideal than the currently accepted industry standard of 50mm.

Back when film cameras were common, 45mm was the industry standard and this continued as reflex cameras needed extra space to fit a mirror. However, as mirrorless cameras become more popular again, there has been a need to return to this industry standard…which is the impetus for the Samyang AF 45mm F1.8 FE. With less distortion than a 35mm lens and wider angles than a 55mm lens, the Samyang AF 45mm F1.8 FE is a perfect lens for portraits, landscapes, architecture photography, and pictures of pets.

What is Preset Aperture Control Function?

On the Preset Aperture Control function, the aperture blade operates smoothly like a "De-clicked lens", which is advantageous for video recording.
Fujifilm cameras are engineered to control the aperture according to the minimum exposure value(F-stop), so when the camera controls the aperture, it blinks momentarily to set the proper exposure.

AF 75mm F1.8 X intentionally disconnects the communication with the camera body and the lens itself on the Preset Aperture Control function, so it is possible to smoothly adjust the exposure without flickering. ISO and shutter speed are adjusted according to the changed exposure by controlling the aperture, so the exposure value can be changed even with the 1/2 F-stop.

What is Preset Aperture Control Function?

On the Preset Aperture Control function, the aperture blade operates smoothly like a "De-clicked lens", which is advantageous for video recording.
Fujifilm cameras are engineered to control the aperture according to the minimum exposure value(F-stop), so when the camera controls the aperture, it blinks momentarily to set the proper exposure.

AF 75mm F1.8 X intentionally disconnects the communication with the camera body and the lens itself on the Preset Aperture Control function, so it is possible to smoothly adjust the exposure without flickering. ISO and shutter speed are adjusted according to the changed exposure by controlling the aperture, so the exposure value can be changed even with the 1/2 F-stop.

What is Recommended Settings for Preset Aperture Control Function?

The Preset Aperture Control function operates only when shooting video(Movie mode) and the focusing mode of the camera is set to AF mode. Please set the aperture at f/1.8 before switching the "Custom Switch" to "Mode 2. It is recommended to set the "Exposure mode" as A mode (Aperture Priority AE) or M mode (Manual Exposure).

* How to use the “Preset Aperture Control” function?

1) Camera Body Setting
      AF Mode → Video Mode ('A' or 'M' mode) → Set the Aperture @F1.8
(2) Lens Setting
      Switch your "Custom Switch” to “Mode 2(M2)"
(3) Now, you're ready to use the Preset Aperture Control function with your focus ring

What is Recommended Settings for Preset Aperture Control Function?

The Preset Aperture Control function operates only when shooting video(Movie mode) and the focusing mode of the camera is set to AF mode. Please set the aperture at f/1.8 before switching the "Custom Switch" to "Mode 2. It is recommended to set the "Exposure mode" as A mode (Aperture Priority AE) or M mode (Manual Exposure).

* How to use the “Preset Aperture Control” function?

1) Camera Body Setting
      AF Mode → Video Mode ('A' or 'M' mode) → Set the Aperture @F1.8
(2) Lens Setting
      Switch your "Custom Switch” to “Mode 2(M2)"
(3) Now, you're ready to use the Preset Aperture Control function with your focus ring

[What is Dolly Shot? How to Shoot Easily]

[What is Dolly shot?]

A dolly shot, also referred to as a tracking shot or trucking shot, is a camera movement technique used by cinematographers to track and follow a subject in motion. To achieve this, the camera is mounted on a device called a "dolly," which facilitates smooth tracking movement. The dolly can move in front of, behind, or alongside the subject, which can be a person, a location, a product, or any other object of focus in the frame. Through this, you can control the emotional distance between the subject and the viewer by highlighting the audiovisual and dramatic effects.

[How to take a Dolly Shot simply by handheld]

Tip. If the moving distance is long, the camera may shake, so please shoot at a focal length between 35 and 100mm.
1. Stand at a distance of about 1.5 to 2 meters away from the subject.
2. Set the custom switch to MF and Mode 3 and adjust the focal length to about 100mm.
3. After focusing on the subject, set the aperture to F8~16.
4. Slowly turn the zoom ring to the left (towards the wide-angle end) while using your upper body and arms to move the camera toward your subject.
5. Dolly Shot complete!
※ When shooting from a farther distance from the subject, use a cart or gimbal for more stable shooting.
